Athena Power AP-AT30 300W AT Power Supply
- Model: n9r89m
- Availability: In stock
-
(0) Write Review
- Description
- Reviews
- Shipping & Returns
Athena Power AP-AT30 300W AT Power Supply 6Pin P8 6pin P9 Connector. The Athena power AP-AT30 300 watt at power supply is good for old style computers or people trying to use them for a specific purpose. *High efficiency* Low Ripple & Noise* Output over voltage protection* Short circuit protection on all outputs * Reset table power shut down* Approved by UL, CB & CE* 6Pin P8 + 6pin P9 AT Connector * FCC part 15 subpart J Class B at 115VAC operation & CISPR 22 Class B at 230 VAC operatio* 100% burn-in under high ambient temperature (50a?aJ)* Vacuum-impregnated transformer* 100% Hi-pot tested* Dimension: 5.75"(W) x 3.25"(H) x 5.5"(D)Power Description:Output Power 300 W Input Voltage 115V / 230V ACFrequency 60/ 50 HzOutput Voltage +5V -5V +12V -12VMAX(A) 30A 0.5A 10A 0.5A MIN(A) 0.5A 0.5A 0.5A 0.5ATechnical Information:Fan Rear FanMTBF 100000 Hours at 25a?aCConnectors 6+6pin AT P8/P9 | 4pin AT Push Button| 4pin Molex | 4pin FDD This power supply is compatible with many old model system, Accounting system, Automatic control machine, storage PCs for power supply replacement.
- Model: AP-AT30
- Brand: Athena Power
- Low Ripple & Noise
- Output over voltage protection
- Short circuit protection on all outputs
- Reset table power shut down
- FCC part 15 subpart J Class B at 115VAC operation & CISPR 22 Class B at 230 VAC operation
- 100% burn-in under high ambient temperature (50 Degrees C)
- 100% Hi-pot tested
- Vacuum-impregnated transformer 100% Hi-pot tested
- 6Pin P8 + 6Pin P9 AT Connector
- Type: AT
- Maximum Power: 300W
- Fans: 1
- +12V Rails: Single
- Power Good Signal: 100-500ms
- Hold-up Time: 16ms min.
- Efficiency: > 70%
- Input Voltage: 115 / 230 V
- Input Frequency Range: 50/60 Hz
- Input Current: 7A @ 115V, 4A @ 230V
- MTBF: >100,000 Hours
- Approvals: UL, CB & CE
- Dimensions: 5.75"(W) x 3.25"(H) x 5.5"(D)
- AT
- 115 / 230 V 50/60 Hz
Manufacturer：Athena Power
MPN：AP-AT30
Maximum Power：300W
Fans：1
PFC：No
+12V Rails：Single
Power Good Signal：100-500ms
Hold-up Time：16ms min.
Efficiency：> 70%
Over Voltage Protection：Yes
Input Voltage：115 / 230 V
Input Frequency Range：50/60 Hz
Input Current：7A @ 115V, 4A @ 230V
MTBF：>100,000 Hours
Approvals：UL, CB & CE
Dimensions：5.75"(W) x 3.25"(H) x 5.5"(D)
Weight：3.05
Features：Low Ripple & Noise
Output over voltage protection
Short circuit protection on all outputs
Reset table power shut down
FCC part 15 subpart J Class B at 115VAC operation & CISPR 22 Class B at 230 VAC operation
100% burn-in under high ambient temperature (50°C)
100% Hi-pot tested
Vacuum-impregnated transformer 100% Hi-pot tested
6Pin P8 + 6Pin P9 AT Connector
