APC P6W Wall Mount 1080 Joules Surge Suppressor

1080 Joule Wall Mount Surge Protector 6 Total Power Surge Protector Outlets When lightning and other conditions cause a power surge, be sure your electronics are protected with an APC Wall-Mounted Surge Protector.The APC SurgeArrest Wall Surge Protector turns a standard AC wall outlet into a 6-outlet surge-protected powerhouse!

• Brand: APC
• Series: SurgeArrest Essential
• Model: P6W
• Outlets: 6
• Outlets Type: NEMA 5-15R
• Cord Length: Wall Mount
• Input Voltage: 120V
• Input Connections: NEMA 5-15P
• Maximum Spike Amperage: 15A
• AC Suppression Joule Rating: 1080 Joules
• EMI/RFI Noise Filter: 40dB
• Color: Beige
• Input Power: 1200W
• Input Frequency: 50 / 60 Hz +/- 5 Hz (auto sensing)
• Peak Current Normal Mode: 60 (/PH) kAmps
• Peak Current Common Mode: 72 kAmps
• NM Surge Response Time (ns): 1 ns
• Let Through Voltage Rating: < 500
• Environmental:
• Operating Tempearture: 0 - 40 ℃
• Operating Relative Humidity: 0 - 95%
• Operating Elevation: 0 - 3000m
• Storage Temperature: -15 - 45 ℃
• Storage Relative Humidity: 0 - 95%
• Storage Elevation: 0 - 15000m
• Dimensions: 4.00" x 1.50" x 5.50"
• Unit Weight: 0.45 lb

• Wall Mount
• 1080 Joules
• 120V

Manufacturer：APC
Classification：SurgeArrest Essential
MPN：P6W
Outlets Type：NEMA 5-15R
Cord Length：Wall Mount
Input Voltage：120V
Input Connections：NEMA 5-15P
Maximum Spike Amperage：15A
AC Suppression Joule Rating：1080 Joules
EMI/RFI Noise Filter：40dB
Color：Beige
Specification：Input Power: 1200 Watts

Input Frequency: 50 / 60 Hz +/- 5 Hz (auto sensing)

Peak Current Normal Mode: 60 (/PH) kAmps

Peak Current Common Mode: 72 kAmps

NM Surge Response Time (ns): 1 ns

Let Through Voltage Rating: < 500

Environmental
Operating Tempearture: 0 - 40 Degree Celcius
Operating Relative Humidity: 0 - 95%
Operating Elevation: 0 - 3000m
Storage Temperature: -15 - 45 Degree Celcius
Storage Relative Humidity: 0 - 95%
Storage Elevation: 0 - 15000m
Features：Lightning and Surge Protection
To prevent damage to your equipment from electric power surges and spikes.

EMI and RFI noise filtering
Reduces line noise that can cause data loss and keyboard errors.

IEEE let-through rating and UL 1449 compliance
The "Institute of Electrical and Electronics Engineers" (IEEE) Let-Through Voltage rating is based on a test that subjects a Surge Protector to a 6,000 volt spike. The rating equates to the amount of excess voltage that reaches connected equipment. The lower the number, the better the performance of the Surge Protector is. Underwriter's Laboratory's UL1449 surge protection safety standard uses these ratings to help users gauge performance. UL's best Transient Voltage Surge Suppressor (TVSS) Let-Through Voltage rating is "300V."

Fail Safe Mode
Most other surge suppressors continue to let power through even after their circuits have been damaged, leaving your equipment exposed to future surges. APC's SurgeArrest fail safe, which means that once the circuit of an APC SurgeArrest has been compromised the unit disconnects equipment from the power supply ensuring that no damaging surges reach your equipment.
Unit Dimensions：4.00" x 1.50" x 5.50"
Unit Weight：0.45 lb.
Package Includes：SurgeArrest Essential P6W 6-Outlets Surge Suppressor
Warranty Card
User Manual
