Asus Prime B350-Plus Amd Ryzen Am4 Ddr4 Hdmi Dvi Vga M.2 Usb 3.1 Atx B350 Motherboard

Powered by AMD Ryzen AM4 processors, the ASUS Prime B350-Plus packs a punch with performance and reliability. Access next-generation connectivity and speeds with NVMe M.2, USB 3.1, DDR4 support and Gigabit LAN. 5X Protection III ensures component longevity and reliability while SafeSlot Core adds protection for PCIe slots.

The Asus PRIME B350-PLUS motherboard supports AM4 processors and will fit in a standard ATX case. This board is powered by the AMD B350 chipset and has support for 4 x 288-pin DIMM memory sticks with a max memory of up to 64GB. You can choose memory speeds of up to DDR4-2133 / 2400 / 2666. This motherboard has 6 SATA ports and 1 x 10/100/1000 Mbps Ethernet built-in. Advanced features of the motherboard include: support for RAID, support for Crossfire, stylish Black / Red design.

• AMD B350
• AMD AM4 Socket for AMD Ryzen/ 7th Generation A-series/Athlon Processors
• * Refer to www.asus.com for CPU support list
• AMD Ryzen Processors
• DDR4 3200(O.C.)/ 2933(O.C.)/ 2666/ 2400/ 2133*1
• AMD 7th Generation A-series/ Athlon Processors
• DDR4 2400/ 2133
• *1 Due to the limitation of AMD Ryzen processors, memory frequencies higher than DDR4 2666 MHz are supported only when using one DIMM per channel.
• * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
• * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists)

Manufacturer：ASUS
MPN：PRIME B350-PLUS
CPU Socket Type：AM4
Processor Type：AMD AM4 Socket for AMD Ryzen/ 7th Generation A-series/Athlon Processors
* Refer to www.asus.com for CPU support list
Chipset：AMD B350
Number of Memory Slots：4×288pin
Memory Standard：AMD Ryzen Processors
DDR4 3200(O.C.)/ 2933(O.C.)/ 2666/ 2400/ 2133*1

AMD 7th Generation A-series/ Athlon Processors
DDR4 2400/ 2133

*1 Due to the limitation of AMD Ryzen processors, memory frequencies higher than DDR4 2666 MHz are supported only when using one DIMM per channel.
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Maximum Memory Supported：64GB
Channel Supported：Dual Channel
PCI Express 3.0 x16：AMD Ryzen Processors
1 x PCIe 3.0/2.0 x16 (x16 mode)

AMD 7th Generation A-series/Athlon Processors
1 x PCIe 3.0/2.0 x16 (x8 mode)
PCI Express 2.0 x16：1 x PCI Express 2.0 x16 slot (max.@x4 mode) *3
*3 PCIeX16_2 slot shares bandwidth with PCIeX1_1 and PCIeX1_2.
PCI Express x1：2 x PCI Express 2.0 x1 slots
PCI Slots：2 x PCI Slots
SATA 6Gb/s：AMD B350 chipset:
4 x SATA 6Gb/s port(s), gray
AMD Ryzen/ 7th Generation A-series/Athlon Processors:
2 x SATA 6Gb/s port(s), gray
M.2 (M key)：AMD Ryzen Processors:
1 x M.2 Socket 3, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x4 mode)*4
AMD 7th Generation A-series/Athlon Processors:
1 x M.2 Socket 3, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x2 mode)*5

*4 The M.2 Socket shares bandwidth with the SATA6G_5/6 ports, therfore the SATA6G_5/6 ports will be disabled when it's occupied
*5 The M.2 Socket shares bandwidth with the SATA6G_5/6 ports, therfore the SATA6G_5/6 ports will be disabled when it's occupied
SATA RAID：0/1/10
Onboard Video Chipset：Integrated AMD Radeon R Series Graphics in the 7th Generation A-Series APU *2
Multi-VGA output support: HDMI/DVI/RGB ports
- Supports HDMI 1.4b max.: 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
- Supports DVI-D max.: 1920 x 1200 @ 60 Hz
- Supports RGB max.: 1920 x 1200 @ 60 Hz
Maximum shared memory of 2048MB

*2 AMD Ryzen Processor does not support.
Audio Chipset：Realtek ALC887
Audio Channels：8 Channels
LAN Chipset：Realtek RTL8111H
Max LAN Speed：10/100/1000Mbps
PS/2：1 x PS/2 keyboard/mouse port
Video Ports：1 x DVI-D port
1 x D-Sub port
HDMI：1 x HDMI
RJ45：1 x RJ45
USB 3.1：2 x USB 3.1 Gen 2 (teal blue)
4 x USB 3.1 Gen 1 (blue)
USB 1.1/2.0：2 x USB 2.0
Audio Ports：3 Ports
Onboard USB：1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
Other Connectors：1 x Fan RGB header
1 x COM port(s) connector(s)
1 x CPU Fan connector(s) (1 x 4-pin)
2 x Chassis Fan connector(s) (2 x 4-pin)
1 x S/PDIF out header(s)
1 x Front panel audio connector(s) (AAFP)
1 x System panel(s)
1 x Clear CMOS jumper(s)
Form Factor：ATX
Dimensions (W x L)：12.0" x 9.35"
Power Pin：1 x 24-pin EATX Power connector(s)
1 x 8-pin ATX 12V Power connector(s)
Features：Multi-GPU Support:
Supports AMD CrossFireX Technology

Special Features:
ASUS 5X Protection III:
- ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
- ASUS Overvoltage Protection: World-class circuit-protecting power design
- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
- ASUS DIGI+ VRM: 6 Phase digital power design
ASUS Exclusive Features:
- AI Suite 3
- Ai Charger
- Turbo LAN
- PC Cleaner
ASUS Quiet Thermal Solution:
- Stylish Fanless Design Heat-sink solution & MOS Heatsink
- ASUS Fan Xpert 2+
ASUS EZ DIY:
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
- Multi-language BIOS
ASUS Q-Design:
- ASUS Q-Slot
- ASUS Q-DIMM

BIOS:
128MB Flash ROM, UEFI AMI BIOS, PnP,WfM2.0,SM BIOS 3.0, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3, My Favorites, Last Modified log, F12 PrintScreen, ASUS DRAM SPD (Serial Presence Detect) memory information, F6 Qfan Control

Operating System:
Windows 10 64-bit
