Thermaltake TR-500 TR2 ATX 500 Watt Power Supply
- Model: z3ffp7
- Availability: In stock
-
(0) Write Review
- Description
- Reviews
- Shipping & Returns
Thermaltake TR2 500W 240-Pin Power Supply TR-500 Thermaltake TR-500 TR2 500W ATX12V v2.3 Power Supply(Core i7 & Core i5 Ready) -Optimized Cable Management-Intelligent 120mm Cooling Fan-Continuous Power Design-Smart over current protections-5 Year Warranty-Maximum Power: 500 Watts-Form Factor: Intel ATX 12V 2.
- 80+ Bronze Certified Power Supply
- This Thermaltake 500w power supply is 80 PLUS Bronze ceritified, meaning you can trust it to be a consistent and sturdy power supply.
- PCI-E Connection
- With a 6+2 pin and 6-pin PCI-E power connector, this Thermaltake TR-500 TR2 ATX 500W Power Supply will allow for a great video card.
- 5 x SATA
- Connect your hard drive, optical drive, and more using the 5 SATA power connectors on this Thermaltake TR2 500W PSU.
- Manufacturer
- Thermaltake
- Model
- TR-500
- Capacity
- 500W
- Fan Size
- 120mm
- Connectors
- 24pin: 1
- ATX 12V 4+4pin: 1
- PCI-E 6+2pin: 1
- PCI-E 6pin: 1
- Molex: 5
- FDD: 1
- SATA: 5
Thermaltake TR2 500w PSU
- Type
- Intel ATX 12V 2.3
- Max. Output Capacity
- 500W
- Color
- Black
- Dimension ( W / H / D )
- 86mm x 150mm x 140mm
- PFC (Power Factor Correction)
- Non PFC
- Power Good Signal
- 100-500 msec
- Hold Up Time
- 16msec (minimum) @ 60% of full load at 115Vac/ 230Vac input.
- Input current
- 8A / 5A
- Input Frequency Range
- 47 Hz - 63 Hz
- Input Voltage
- 115 Vac / 230 Vac
- Operating Temperature
- 0?C to +50?C
- Operating Humidity
- 20% to 90%,non-condensing
- Storage Temperature
- -20 ?C to +70 ?C
- Storage Humidity
- 5% to 95%, non-condensing
- Cooling System
- 120mm Fan: 2000 R.P.M. +/- 10%
- MTBF
- 100,000 hrs minimum
- Safety Approval
- UL/CUL/FCC
- PCI-E Connector
- PCI-E 6+2pin x 1, PCI-E 6pin x 1
Thermaltake TR-500
Manufacturer：Thermaltake
Classification：TR2
Maximum Power：500W
Fans：1
Modular：No
