Rosewill HIVE 650W 80+ Bronze Semi-Modular ATX Power Supply Hive-650S

Power your new system with Rosewill's HIVE 650W 80PLUS Bronze ATX power supply. This power supply delivers continuous 650 watts of safe, reliable output for your computer. The unit is SLI and CrossFire ready so you can enjoy high-fidelity gameplay. Its 80PLUS Bronze certification ensures it provides superior power efficiency of 82% between 20% and 100% resulting in lower heat output and higher cost-savings. The unit comes with protection from most hazards to provide maximum safety for your system's components. A silent 135mm fan with automatic speed control delivers excellent cooling for the unit while maintaining silence.

Features

• 80 PLUS BRONZE Certified
• Continuous 650W@40 C
• Single strong 12V rail - ideal for Gaming system
• SLI & CrossFire ready - 2x 6+2pin Connector
• 1x Silent 135mm Fan with auto fan speed control
• Active-PFC with auto AC-input voltage adjustment(115-230V)
• Mesh sleeve on all cables for easier cable routing and better ventilation
• Over Temperature/Current/Voltage/Power Protection, Under Voltage Protection, and Short Circuit Protection provide maximum safety to your critical system components
• 3-year Warranty - One-to-One replacement
• Safety & EMI Approval: UL, FCC, CE, CB, ROHS

Product Specifications

Brand

Rosewill

Model

HIVE-650S

Type

ATX12V v2.31 & EPS12V v2.92

Maximum Power

650W

Fan

1 x Silent 135mm

PFC

Active

Main Connector

20+4 Pin

+12V Rails

SLI Ready

Yes

CrossFire Ready

Yes

Haswell Support

Yes

Modular

Semi

Power Good Signal

100-500ms

Hold-up Time

> 16ms

Efficiency

> 82% Up to 87%

Energy Efficiency

80PLUS Bronze

Over Voltage Protection

Yes

Overload Protection

Yes

Input Voltage

115 / 230 V

Input Frequency Range

47 - 63 Hz

Input Current

10A

Output+3.3V@22A,+5V@22A,+12V@48.75A,-12V@0.3A,+5VSB@2.5A

MTBF

100k hours at 25 C, max. load, nominal input

Approvals

UL, CB, CE, FCC, ROHS

Dimensions (H x W x D)

3.39" x 5.91" x 6.30"

Weight

5.5lbs

• 650 Watt Power Supply
• ATX 12V v2.31 / EPS 12V v2.92 100 - 240 V 50 / 60 Hz
• 80 PLUS BRONZE Certified
• Continuous 650W @ 40 Degree Celsius
• Full Modular Design PSU
• SLI Ready / CrossFire Ready / Intel 4th Gen CPU Certified
• Silent 135mm Fan
• Strong Single +12V Rail

Manufacturer：Rosewill
MPN：HIVE-650S
Classification：HIVE Series
Type：ATX12V v2.31 & EPS12V v2.92
Maximum Power：Continuous 650W@40 Degree Celsius
Fans：1 x Silent 135mm Fan
PFC：Active
Main Connector：20+4Pin
+12V Rails：Single
PCI-Express Connector：2 x 6+2-Pin
SATA Power Connector：8
SLI：SLI Ready
Haswell Support：Yes
CrossFire：CrossFire Ready
Modular：Full Modular
Power Good Signal：100-500ms
Hold-up Time：> 16ms
Efficiency：> 82%, Up to 87%
Energy-Efficient：80 PLUS BRONZE Certified
Input Voltage：115 / 230 V
Input Frequency Range：47 - 63 Hz
Input Current：10A
Output：+3.3V@22A, +5V@22A, +12V@48.75A, -12V@0.3A, +5VSB@2.5A
MTBF：100k hours at 25 Degree Celsius, max. load, nominal input
Approvals：TUV, cTUVus, CE, FCC certified
Dimensions：3.39" x 5.91" x 6.30"
Weight：5.50 lbs.
Connectors：Fixed Cable:
1 x 20+4-Pin Main Connector
1 x 4+4-Pin ATX12V/EPS12V Connector
Modular Cable:
2 x 6+2-Pin PCI-E Connector
8 x 5-Pin SATA Connector
4 x 4-Pin Peripheral Connector
2 x 4-Pin Floppy Connector
Features：80 PLUS BRONZE Certified
Continuous 650W@40 Degree Celsius
Single strong 12V rail - idea for Gaming system
SLI & CrossFire ready - 2x 6+2-pin Connector
1 x Silent 135mm Fan with auto fan speed control
Active-PFC with auto AC-input voltage adjustment (115 - 230V)
Mesh sleeve on all cables for easier cable routing and better ventilation
Over Temperature / Current / Voltage / Power Protection, Under Voltage Protection, and Short Circuit Protection provide maximum safety to your critical system components
Safety & EMI Approval: UL, FCC, CE, CB, ROHS
