Athena Power BP-1225U32SAC USB 3.0 Super Speed 5.25 Drive Bay Extended Backplane Module
- Model: acfmvy
- Availability: In stock
-
(0) Write Review
- Description
- Reviews
- Shipping & Returns
Athena Power BP-1225U32SAC USB 3.0 Super Speed 5.25" Drive Bay Extended Backplane Module. An Enterprise Grade Extended Module for Converting 1 x 5.25" Drive Bay to 2 x Hot-Swap 2.5"SSD/HDD and 2 x 2-Port Superspeed USB3.0. Give your PC more USB 3.0's and easy hard drive access
Easy to install and easy to hook up. Use this to install a drive you want access to in the front tray of your system where you can swap it in and out or take it with you. Blue led lights up on tray with installed drive. Drive trays eject easily and although they have locks on them you don't need to lock the drive to use it. Great upgrade to any build. The hard drive caddy gives you plenty of space for air circulation and anti-vibration springs to dampen noise. This backplane supports SAS & SATA interfaces along with enterprise grade 2.5” HDDs.
- Model: BP-1225U32SAC
- Product Category: Internal
- Product Sub Category: Obsidian Series (Enterprise Grade Extended Module)
- Form Factor: 5.25"
- Interface: SATA/SAS Interface
- Trayless Design: No
- Supported HDD Size: 2 x 2.5" SAS(III,II,I)/SATA(III,II,I) SSD/HDD
- Support Enterprise Grade 2.5" HDD (Height up to 15mm)
- Hot-Swappable: Hot-Swappable
- Cage Color: Silver/Black
- Cooling Fan: None
- Material:T=1.2mm SECC
- Power Connector: 1 x SATA 15Pin
- HDD Connection: 4 x SATA 7Pin (Dual Channel function)
- Transfer Rate: Up to 12Gb/s
- RoHS Ready: RoHS Ready
- Door & Lock: 2 x Metal Triangle Key-lock (on each of HDD tray)
- Dimension: (W x H x D) 5-3/4 x 1-5/8 x 6
- Weight: 2.00lb
- Warranty: 1 Year Manufacture Limited Warranty
Manufacturer：Athena Power
MPN：BP-1225U32SAC
Type：Backplane Module
Color：Black
Specifications：Form Factor: 5.25"
Interface: SATA / SAS Interface
Supported HDD Size: 2 x 2.5" SAS (III,II,I) / SATA (III,II,I) SSD / HDD Support Enterprise Grade 2.5" HDD (Height up to 15mm)
Hot-Swappable: Hot-Swappable
USB 2.0 & USB 3.0 Combo all four ports
Cage Color: Silver / Black
Material: T=1.2mm SECC
Power Connector: 1 x SATA 15Pin
Transfer Rate: up to 12Gb/s
RoHS Ready: RoHS Ready
Door & Lock: 2 x Triangle Key-lock
