ADATA XPG SX8000 M.2 2280 128GB PCI-E 3.0 x4 MLC Internal Solid State Drive (SSD) ASX8000NP-128GM-C

ADATA XPG SX8000 PCIe 128GB 3D NAND MLC NVMe Gen3x4 M.2 2280 Solid State Drive (ASX8000NP-128GM-C). XPG SX8000 PCIe Gen3x4 NVMe M.2 (2280) SSD. Unleash the true power of SSD with PCIe interface - Hardcore gamers and serious computing enthusiasts have long been prevented from taking full advantage of SSD performance because of SATA interface that limits SSD read speed to less than 600MB/s. SATA-interface SSD can easily outperforms conventional HDD but is still far from utilizing the full potential of SSD. XPG SX8000 changes that by eliminating the SATA bus interface bottleneck and giving true enthusiasts out-of-this-world gaming experience.

Outrank comparable models with outstanding capacity and durability. Due to the flexibility of 3D NAND, we can offer the SX8000 M.2 2280 SSD in diverse capacities, ranging from 128GB to 1TB while keeping its compact form factor. Moreover, 3D NAND outperforms 2D NAND and offers higher efficiency and reliability. All SX8000 models provide high TBW (Total Bytes Written), meaning the number of times an SSD can write its entire capacity in one lifespan. The SX8000 has a TBW rating that outranks comparable models, indicating SX8000 a longer-lasting SSD.

• Brand: ADATA
• Series: XPG SX8000
• Model: ASX8000NP-128GM-C
• Device Type: Internal Solid State Drive (SSD)
• Used For: Consumer
• Form Factor: M.2 2280
• Capacity: 128GB
• Memory Components: MLC
• Interface: PCI-Express 3.0 x4
• Controller: SMI 2260
• Max Sequential Read: Up to 1000 MBps (ATTO); Up to 1000 MBps (CDM QD32); Up to 900 MBps (AS SSD)
• Max Sequential Write: Up to 300 MBps (ATTO); Up to 300 MBps (CDM QD32); Up to 280 MBps (AS SSD)
• 4KB Random Read: Up to 45,000 IOPS
• 4KB Random Write: Up to 75,000 IOPS
• MTBF: 2,000,000 hours
• HeatSink: No
• Power Consumption (Idle): 0.14W
• Power Consumption (Active): 0.33W
• Operating Temperature: 0°C ~ +70°C
• Storage Temperature: -40°C ~ +85°C
• Max Shock Resistance: 1500G/0.5ms
• Height: 3.50mm
• Width: 22.00mm
• Depth: 80.00mm
• Weight: 8.00g

• M.2 2280
• 128GB
• NVMe PCI-Express 3.0 x4

Manufacturer：ADATA
Classification：XPG SX8000
MPN：ASX8000NP-128GM-C
Device Type：Internal Solid State Drive (SSD)
Used For：Consumer
Form Factor：M.2 2280
Size：128GB
Memory Components：MLC
Interface：NVMe PCI-Express 3.0 x4
Controller：SMI 2260
Max Sequential Read：Up to 1000 MBps (ATTO)
Up to 1000 MBps (CDM QD32)
Up to 900 MBps (AS SSD)
Max Sequential Write：Up to 550 MBps (ATTO)
Up to 550 MBps (CDM QD32)
Up to 500 MBps (AS SSD)
4KB Random Read：Up to 45,000 IOPS
4KB Random Write：Up to 75,000 IOPS
MTBF：2,000,000 hours
HeatSink：No
Features：Ultra-fast PCIe Gen3 x4 interface: R/W speed up to 2500/1100 MB/S

NVMe 1.2 certified

3D MLC NAND Flash

Advanced LDPC ECC technology

Intelligent SLC caching and DRAM cache buffer

RAID Engine and Data Shaping

Compact M.2 2280 form factor - ideal for gaming notebooks and high-end desktops
Power Consumption (Idle)：0.14W
Power Consumption (Active)：0.33W
Operating Temperature：0°C ~ +70°C
Storage Temperature：-40°C ~ +85°C
Max Shock Resistance：1500G/0.5ms
Height：3.50mm
Width：22.00mm
Depth：80.00mm
Weight：8.00g
