Phanteks PH-TC12DX_BK Dual 120mm PWM CPU Cooler
- Model: rxmnu3
- Availability: In stock
-
(0) Write Review
- Description
- Reviews
- Shipping & Returns
This Phanteks PH-TC12DX Dual 120mm CPU Cooler is built for the least amount of air and thermal resistance. The heatpipes are 6mm thick and are U-shaped. Two PH-F120HP Premium Fans are included for better performance or quiet operation.PHANTEKS PH-TC12DX, U-type for Intel LGA 2011,1155,1156,1366, 775, and AMD AM2/AM2+/AM3+/FM 1/2, 4xψ6mm Dual Heat-pipes with patented P.A.T.S and C.P.S.C Technologies, Dual 120mm premium PWM Fans, Black _ Retail
- Copper (Base and Heat-pipes), Nickel Plated
- Aluminum (Fins and Top Cover)
- Patented P.A.T.S (Physical Anti-Oxidant Thermal Shield)
- Patented C.P.S.C (Cold Plasma Spraying Coating)
- Fan Model: PH-F120HP PWM Premium Fan
- 600 - 1800 RPM +/-10%
- 23 - 68.5 CFM
- Aluminum & Copper
Manufacturer：Phanteks
Classification：PH-TC12DX
MPN：PH-TC12DX_BK
Type：Fan & Heatsinks
Fan Size：2 x 120 mm
Compatibility：Intel LGA 2011 / 1366 / 1156 / 1155 / 1150 / 775
AMD FM2 / FM1 / AM3+ / AM3 / AM2+ / AM2 (Stock back-plate required)
Bearing Type：UFB (Updraft Floating Balance)
RPM：600 - 1800 RPM +/- 10%
Air Flow：23 - 68.5 CFM
Noise Level：21.9 - 27.6 dBA
Power Connector：4 Pin
Color：Black
Heatsink Material：Copper (Base and Heat-pipes), Nickel Plated
Aluminum (Fins and Top Cover)
Unique P.A.T.S (Physical Anti-Oxidant Thermal Shield)
Unique C.P.S.C (Cold Plasma Spraying Coating)
Fan Mounting Types to Heatsink：Horizontal
Max CPU Cooler Height：157 mm
Fan Dimensions：120.00 x 120.00 x 25.00 mm
Heatsink Dimensions：157.00 x 57.00 x 126.00 mm w/o fans
157.00 x 107.00 x 126.00 mm w/ dual fans
Weight：1.34 lbs.
1.94 lbs. w/ fans
Features：P.A.T.S (Physical Antioxidant Thermal Shield) will greatly increase the cooling performance and reliability while deflecting other thermal radiation from other heat sources, such as the GPU, South Bridge, North Bridge, etc. P.A.T.S, ran at a long period, will display significantly better results in an enclosure, closed environment, than a tech station, open environment. In extreme conditions, PATS is able to withstand temperatures of up to 200 degrees Celsius. P.A.T.S is environmental friendly and non-toxic.
C.P.S.C (Cold Plasma Spraying Coating Technology) is a brand new technologic forming deposit that displaces heat onto corresponding metals at a quicker rate. With this technology, the Phanteks PH-TC12DX enhances thermal conductivity on the soldered surfaces of the heat-pipes through the copper deposits.
Phanteks PH-F120HP PWM Premium fans uses UFB (Updraft Floating Balance) bearing, Nine blades and MAFO (Maelstrom Air-Fort Optimization) drive system to achieve massive airflow and perfect dynamic balance. The PH-F120HP fans with the support of the anti-acoustic rubber pad and rubber bar produces low level dB(A) and eliminates vibration. With PWM functions built in, PH-F120HP fans allows you to set speed adjustments for either performance and/or silent operation.
SoliSku universal mounting kit provides broad socket compatibilities for Intel LGA 2011 / 1150 / 1155 / 1156 / 1366 / 775 and AMD FM2 / FM1 / AM3+ / AM3 / AM2+ / AM2 (Stock back-plate required).
Phanteks PH-NDC is made of high purity Nano diamond-like particles to improve the thermal conductance between components. The PH-NDC is a superb quality thermal compound for heat-sinks. Heat generated by CPUs will transfer to the heat-sinks without reduction in efficiency and resistance.
Package Includes：1 x PH-TC12DX Heatsink
2 x PH-F120HP PWM Premium Fans
8 x Fan Clip Adapters
4 x Rubber Bar
4 x Fan wire clips (PH-F120HP Fan's Accessories)
SoliSku Mounting Kits for Intel and AMD (Stock back-plate required)
1 x Y Fan Splitter (4pin)
1 x PH-NDC Thermal Compound
2 x Phanteks PH-TC12DX User's Manual
