Monoprice 8150 2x1 Mini HDMI Switch w/ Optional Power Input
- Model: lqqm4e
- Availability: In stock
-
(0) Write Review
- Description
- Reviews
- Shipping & Returns
When all you need is a simple switch to choose between two input source devices, you will be hard pressed to find a better solution than the Monoprice 2x1 Mini HDMI Switch. Note that this switch has regular HDMI Connectors. The "mini" in the title and description refer to the size of the switch, not the type of connectors it uses. This small switch automatically switches between two input devices, depending upon which one is turned on. It is powered by the HDMI source, so no external power supply is required (though one can optionally be used if one of the devices has a weak signal output strength). The switch handles High Speed (1080p) signals with High Definition audio and 12-bit per channel Color Depth. A manual switching option is available via a button on the top of the unit, in case you don't want to turn off the unused source or your source continues to power the HDMI cable when in standby mode. Note: Monoprice strongly recommends the use of minimum 24 AWG HDMI cables when connecting a device, such as this switch, between the source and destination devices to ensure minimal signal loss and maximum High Speed signal reliability.
- Switch automatically switches between input devices
- Power provided by HDMI source
- Switch can handle 1080p and 12-bit per channel Color Depth
- Model
- 8150
- Maximum Video Resolution
- 1920x1080 (1080p)
- Vertical Frequency Range
- 50/60Hz
- Video Amplifier Bandwidth
- 250 MHz / 2.5 Gbps per channel
- Supported Video Resolutions
- 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
- Color Depth
- 12-bits per channel (36-bit total)
- Supported Audio Formats
- LPCM, Digital DTS, Dolby Digital, DTS-HD Master Audio, and Dolby TrueHD
- Input Power Requirement
- none required (5V DC optional)
- Power Consumption
- 5 Watts
- Operating Temperature
- 0 Degrees C to +70 Degrees C
- Operating Humidity
- 10% to 85% RH (no condensation)
- Storage Temperature
- -10 Degrees C to +80 Degrees C
- Storage Humidity
- 5% to 90% RH (no condensation)
- Dimensions
- 3 13/32" wide by 1 3/4" deep by 5/8" tall
- Weight
- 42 grams
- This small switch automatically switches between two input devices depending upon which one is turned on
- It is powered by the HDMI source so no external power supply is required
- Monoprice strongly
Manufacturer：Monoprice
Classification：108150
