LEPA G Series G1600-MA 1600W ATX12V / EPS12V SLI/CrossFire Ready 80 PLUS GOLD Certified Full Modular
- Model: 3jhomv
- Availability: In stock
-
(0) Write Review
- Description
- Reviews
- Shipping & Returns
This LEPA G1600 Power Supply comes rated with 1600-Watts output, peak power up to 1700-Watts. Surpassing 80 Plus Gold level (G1600-MA is 80 Plus Gold certified.) Full Modular Cabling Design makes system upgrade and replacement easy. High Density PCB Design makes G1600 only 18cm in depth, providing more space to dissipate the heat inside the chassis. 135mm ball bearing fan with thermal programmed speed controller delivers silent, cool operation. Honeycomb-shaped ventilation design increases airflow and keeps power supply cool. Solid State Capacitors and 105 degree C Japanese Grade A Capacitors provide great reliability. DC-to-DC Converter Design ensures system stability. Full Bridge and Zero Voltage Switch (ZVS) topologies provide superior performance and reliability. Dual Sided PCB design synergizes PCB layout. Six powerful +12V rails with high maximum loads offer great compatibility with heavy-duty graphics cards. Ability to run up to 4-Way GPU (SLI / Crossfire) and Dual CPUs together effortlessly. Compliance with EU ErP Lot 6 standards (lower than 1W power consumption at standby mode). Over Power, Over Voltage, Under Voltage, Over Current, Over Temperature, Short-circuit protection provide great safety to your system. ATX12V version 2.3 and EPS12V version 2.92 compliant.
- ATX12V / EPS12V
- Full Modular
- 80 PLUS GOLD Certified
- 115 - 240 V 50/60 Hz
- +3.3V@25A,+5V@25A,+12V1@20A,+12V2@20A,+12V3@30A,+12V4@30A,+12V5@30A,+12V6@30A,-12V@0.5A,+5Vsb@4A
Manufacturer：LEPA
MPN：G1600-MA
Classification：G Series
Type：ATX12V / EPS12V
Maximum Power：1600W
Main Connector：24Pin
PCI-Express Connector：10 x 6+2-Pin
SATA Power Connector：14
SLI：SLI Ready
Haswell Support：Yes
CrossFire：CrossFire Ready
Modular：Full Modular
Efficiency：> 90%
Energy-Efficient：80 PLUS GOLD Certified
Input Voltage：115 - 240 V
Input Frequency Range：50/60 Hz
Input Current：16-8A
Output：+3.3V@25A,+5V@25A,+12V1@20A,+12V2@20A,+12V3@30A,+12V4@30A,+12V5@30A,+12V6@30A,-12V@0.5A,+5Vsb@4A
MTBF：>100,000 Hours
Approvals：FC,80 Plus
Dimensions：7.09" x 5.91" x 3.39" (D x W x H)
Weight：5.29 lbs.
Connectors：1 x Mainboard 24P
2 x +12V CPU 8P
1 x +12V CPU 4P
10 x 4P Molex
14 x SATA
2 x FDD
10 x 6+2P (8P) PCI-E
