EVGA SuperNOVA 220-G2-0850-XR 850G2 80PLUS Gold 850W ATX Power Supply
- Model: h6y7xw
- Availability: In stock
-
(0) Write Review
- Description
- Reviews
- Shipping & Returns
This EVGA SuperNOVA 850G2 80PLUS Gold 850W ATX Power Supply is able to give your system to power it needs to make it a great gaming PC. With 8x PCI-Express power connectors, 10x SATA, 4x Molex, 2x EPS, 24-pin ATX, and an FDD connector, you'll be able to equip your system with the hardware necessary to become a high-performance workstation or gaming system.
EVGA SUPERNOVA 850/750 G2 POWER SUPPLIES
NEXT GENERATION IN POWER
Unleash the next generation in power with the EVGA SuperNOVA 850/750 G2 Power Supplies. Based on the award winning G2 series Power Supplies from EVGA, these PSUs feature 80 PLUS Gold rated efficiency, and clean, continuous power to every component. The new ECO Thermal Control Fan System offers fan modes to provide zero fan noise during low load operations. This provides improved efficiency for longer operation, less power consumption, reduced energy costs and minimal heat dissipation. Backed by a 10 year warranty and Japanese capacitor design, the EVGA SuperNOVA 850/750 G2 is not only the right choice for your system today, it is also the best choice for your system tomorrow.
- 80 PLUS Gold Certified Power Supply
- 850W Max output
- 8x PCI-e power connectors total
- 10x SATA Connectors
- ATX CABLE
- 1x 600mm (m)
- EPS CABLE
- 2x 700mm (m)
- PCIE CABLE
- 2x 700mm, 850mm (m) 2x 700mm (m)
- SATA CABLE
- 2x 550mm, 650mm, 750mm (m) 1x 550mm, 650mm, 750mm, 850mm (m)
- FOUR-PIN PERIPHERAL CABLE
- 1x 550mm, 650mm, 750mm, 850mm (m)
- FLOPPY ADAPTER
- 1x 100mm
- AC POWER
- 1x 1500mm (m)
- MODULAR CABLE TYPE
- Full
- 24 PIN ATX
- 1x
- EPS (CPU)
- 2x 8pin (4+4)
- PCIE
- 4x 8pin (6+2), 2x 6pin
- SATA
- 10x
- FOUR-PIN PERIPHERAL
- 4x
- FLOPPY
- 1x
- OPERATING TEMPERATURE
- 0 Degrees to 50 Degrees C
- JAPANESE CAPACITORS
- 100%
- ECO MODE
- Yes
- MTBF
- 100,000 Hours
- NET WEIGHT
- 8 lbs
- SIZE
- 85mm (H) x 150mm (W) x 180mm (L)
- APPROVALS
- TUV, CB, CE, FCC, RCM, cTUVus, BSMI, WEEE, RoHS
- Compliance with ErP Lot 6 2013 Requirement
- FAN SIZE / BEARING
- 140mm Double Ball Bearing
CABLE LENGTH
CONNECTOR QUANTITY
ADDITIONAL DETAILS
- ATX12V / EPS12V
- Full Modular
- 80 PLUS GOLD Certified
- SLI CrossFire Ready
- Intel 4th Gen CPU Compatible
- 100 - 240 V 50/60 Hz
Manufacturer：EVGA
MPN：220-G2-0850-XR
Classification：SuperNOVA
Type：ATX12V / EPS12V
Maximum Power：850W
Fans：1 x 140mm Double Ball Bearing Fan
Main Connector：24Pin
+12V Rails：Single
PCI-Express Connector：2 x 6-Pin, 4 x 6+2-Pin
SATA Power Connector：10
SLI：SLI Ready
Haswell Support：Yes
CrossFire：CrossFire Ready
Modular：Full Modular
Efficiency：90% (115VAC) / 92% (220VAC - 240VAC)
Energy-Efficient：80 PLUS GOLD Certified
Input Voltage：100 - 240 V
Input Frequency Range：50 - 60 Hz
Input Current：10A
Output：+3.3V@24A, +5V@24A, +12V@70.8A, +5Vsb@3.0A, -12V@0.5A
MTBF：100,000 Hours
Approvals：TUV, CB, CE, FCC, RCM, cTUVus, BSMI, WEEE, RoHS, Compliance with ErP Lot 6 2013 Requirement
Dimensions：3.35" x 5.91" x 7.09"
Weight：6.00 lbs.
Connectors：1 x 24-Pin ATX
2 x 4+4-Pin EPS12V
4 x 6+2-Pin PCI-E
2 x 6-Pin PCI-E
10 x SATA
4 x 4-Pin Peripheral
1 x Floppy
Features：80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC - 240VAC) efficiency or higher under typical loads
Highest quality Japanese brand capacitors ensure long-term reliability
Fully Modular to reduce clutter and improve airflow
NVIDIA SLI & AMD Crossfire Ready
Double Ball Bearing fan for exceptional reliability and quiet operation
Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), and SCP (Short Circuit Protection)
