EVGA 500 BR 100-BR-0500-K1 500W Power Supply
- Model: q8k6kv
- Availability: In stock
-
(0) Write Review
- Description
- Reviews
- Shipping & Returns
Introducing the EVGA BR Series of power supplies. Designed with both beginner and enthusiast needs in mind, EVGA power supplies are the best choice to power next generation computers. Combining 500W of continuous power with exceptional performance, stunning efficiency, and reliable quality, the 500W BR power supply is what you need to build a solid foundation for your next system. Features a non-modular design with all black full sleeved cables for that high end aesthetic, 120mm sleeve bearing quiet fan, increased 3.3V/5V voltage stability, all backed by EVGA's World Leading Warranty and Support for 3 Years.
- Single 12V Rail
- 3 Year Warranty
Manufacturer：EVGA
MPN：100-BR-0500-K1
Classification：500 BR
Type：ATX12V / EPS12V
Maximum Power：500W
Fans：1 x 120mm Long Sleeve Bearing Fan
PFC：Active
Main Connector：24Pin
+12V Rails：Single
PCI-Express Connector：2 x 6+2-Pin
SLI：SLI Support
Haswell Support：Yes
Modular：Non-Modular
Efficiency：85% Efficiency
Energy-Efficient：80 PLUS BRONZE Certified
Input Voltage：100 - 240 V
Input Frequency Range：50/60 Hz
Input Current：8 - 4 A
Output：+3.3V@20A, +5V@20A, +12V@41.7A, +5Vsb@3A, -12V@0.3A
MTBF：100,000 Hours
Approvals：TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
Compliance with ErP Lot 6 2013 Requirement
Dimensions：3.35" x 5.91" x 5.51"
Weight：4.00 lbs.
Connectors：1 x 24 Pin ATX
1 x 8pin (4+4) EPS (CPU)
2 x 8pin (6+2) PCIE
6 x SATA
3 x Four-Pin Peripheral
1 x Floppy
