MonoPrice 8120 HDMI Extender Equalizer Repeater - Extends to 114ft/35m
- Model: mtmhrb
- Availability: In stock
-
(0) Write Review
- Description
- Reviews
- Shipping & Returns
Use this MonoPrice 8120 HDMI Repeater to extend the length of your HDMI signal by up to 35m. Supporting HDCP pass-through as well as DTS Digital and Dolby® Digital, you'll have no problems with the high resolution video or audio signals. "L" shaped brackets are included, allowing for mounting to a flat surface. Anchor nuts are also provided above each HDMI port to allow to place a securing bracket to ensure it does not get unplugged unintentionally.
- Extends HDMI signal up to 35m
- Supports HDCP
- Supports DTS Digital, Dolby Digital
- Input Signal
- HDMI , 5 volts p-p (TTL)
- Input Video Amplifier Bandwidth
- 2.25 Gbps/165 MHz
- Interlaced Resolutions (50 & 60 Hz)
- 480i, 576i, 1080i
- Progressive Resolutions (50 & 60 Hz)
- 480p, 576p, 720p, 1080p
- External Power Supply
- 5V DC @ 2A (optional) with 5.5 mm barrel and 2.5 mm pin size
- Power Consumption (Max)
- 3W
- Operating Temperature
- 0° C to +70° C
- Operating Humidity
- 10% to 85% RH (no condensation)
- Storage Temperature
- -10° C to + 80° C
- Storage Humidity
- 5% to 85% RH (no condensation)
- Size (W-H-D)
- 50 x 40 x 35 mm
- Weight (Net)
- 78 g
- Regulatory Approvals
- FCC, CE, UL
- Extend The Distance You Can Run High Speed Hdmi Cables With Full 1080p Support To Up To 35 Meters With This Hdmi Repeater!
- The Adjustable Equalizer Allows You To Tune The Performance Of The Repeater
Manufacturer：Monoprice
Classification：108120
